    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector

    Ask Lasest Price
    Model Number : HW PLC Splitter
    Brand Name : FIbconet
    Price : $11.00/boxes 500-4999 boxes
    • Product Details
    • Company Profile

    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector

    VR
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    High Quality 1X5 Single mode Fiber Optic FTTR fiber front Cassette Fiber Splitter PLC SC/APC casette type PLC splitter
    Product Description


    Fiber optic gpon splitter is an indoor optical routing product, featuring increased internet speed and extended wifi range which can also control smart appliances. We can provide you with the best price and customize services for your specific needs. Our factory have a large Production capacity as 50000 pieces /month.
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector

    APPLICATIONS

    · LAN, WAN and Metro Networks
    · FTTH project & FTTX Deployments
    · CATV System
    · GPON, EPON
    · Fiber Optic Test Equipment
    · Data-base Transmit Broadband Net
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector

    FEATURE

    · Low Insertion loss
    · Low PDL
    · Compact Design
    · Good channel-to-channel uniformity
    · Wide Operating Wavelength: 1260-1650nm
    · Wide Operating Temperature: -40°C - 85°C
    · High Reliability and Stability
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    Related products
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    Specification parameters
    1×5
    Wavelength range
    1260nm~1650nm

    Insertion loss(dB)
    Maximum
    85%
    ≤2.0
    Minimum
    15%
    ≤16.0
    Polarization-related loss(dB)
    Maximum
    0.2
    15% channel uniformity(dB)
    Maximum
    0.8
    Return loss(dB)
    Minimum
    50
    Directivity(dB)
    Minimum
    55
    Fiber type
    G657A2
    Output end loose bushing type colour
    Input:900μm, Hytrel, White
    85%Output:900μm, Hytrel, Green
    15%Output:900μm, Hytrel, White
    Company Profile
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1X5 Single mode Fiber Optic FTTR PLC Splitter Cassette for Upc/APC Endface Connector
    1. Are you a manufacturer or trade company? We are the manufacturer with nearly 20 years' history. 2. What is your fiber brand ? Our fiber brand include: YOFC, Corning, Fiber Home, J-fiber, POFC 3. How can we place order? Parameter Confirmation - Proforma Invoice Preparation - Deposit - Production & Dlivery 4. What is the quality for your product? Free sample is provided for your testing. All of our product are with high quality, we promise 100% recall policy if they are unqualified, we can write it into our contract! 5. How do you arrange the shipping? Solution A: FIBCONET take care of everything. Clients only need to collect cargo in local or wait cargo delivery to their office. There are two types of shipping methods available, by sea and by air (Express courier - FedEx/ DHL/UPS/TNT/EMS, we can ship them according to your express account or ship them by our agent company, the delivery time is about four days). Solution B: Clients assign a Shenzhen logistic company to do the shipping, FIBCONET follow the company's instructions and finish the shipping. 6. How can you guarantee the delivery time? To avoid the delay, we have built a complete and professional procedure system from production to the deliver and have rich experience. We can regulate the penalty clause in the contract for the late delay. 7. What's your best price for your passive fiber optic product? Based on the quality of our products and the quantity of your estimated. We would quote the great best matching price all the time. 8. What is your quality control for your fiber optic product ? 1. Source Guarantee. We have our own long-term cooperation raw material suppliers. All the products are ROHS certificated and satisfy exporting quality level demand. 2. Quality Test. It runs through the whole process from the raw material to finished product, such as package, surface, physical test, optical test. They are 100% tested. 3. Optical Test. Our products are strictly tested in accordance with IEC and ITU standard. 4. 30% spot test by Quality Assurance Department after the products finished. 9. Why choose FIBCONET Fiber Optic to cooperate? 1. First-class production line and strict quality management system. 2. Professional procedure system and big production capacity to guarantee fast delivery and on time shipment. 3. Most competitive price to meet your budget. 4. Rich Experience in design and innovate the new products. 5. Professional team to provide comprehensive one-stop service for you. Please always feel free to contact us for any questions, it's chance for both to know each other!
