    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3

    Ask Lasest Price
    Model Number : 1x 4 plc splitter
    Brand Name : FIBCONET
    Supply Ability : 200000 Piece/Pieces per Month
    Price : $3.60/pieces 100-999 pieces
    • Product Details
    • Company Profile

    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3

    Products Description
    Our 1x4/1x8 PLC Splitter is a reliable and cost-effective solution for splitting fiber optic signals. Fiber optic splitter is designed to split one input signal into eight output signals, making it ideal for use in FTTx applications such as FTTH, FTTC, and FTTB.
    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3
    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3
    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3
    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3
    Application
    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3






    APPLICATIONS
    · FTTx
    · Cable television (CATV)
    · Local area networks (LAN)
    · Test equipment
    · Passive optical networks(PON)


    FEATURE
    · Wide operating wavelength range: from 1260nm to 1650nm
    · Wide Operating Temperature: from -40ºC to 85ºC
    · Good channel-to-channel uniformity
    · High reliability and small size
    · Adopt high-strength stainless steel, pass the salt spray test
    · Adopt 100% new raw material, ROHS compliance
    · Low Insertion loss&Low PDL Compact Design
    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3
    Product Paramenters
    1xN PLC Splitter Specification
    Operating Wavelength(nm)
    1260~1650
    Fiber Type
    G657A1 or as customers' order
    Port Configuration
    1x2
    1x4
    1x8
    1x16
    1x32
    1x64
    1x128
    Insertion Loss (dB)
    3.8/4.0
    7.1/7.3
    10.2/10.5
    13.5/13.7
    16.5/16.9
    20.5/21.0
    23.8/24.2
    Loss Uniformity (dB)
    0.4
    0.6
    0.8
    1.2
    1.5
    2.0
    2.5
    Polarization Dependent Loss(dB)
    0.2
    0.2
    0.2
    0.25
    0.3
    0.35
    0.4
    Wavelength Dependent Loss(dB)
    0.3
    0.3
    0.3
    0.5
    0.5
    0.5
    0.5
    Temperature Dependent Loss (-40~85 ) (dB)
    0.4
    0.4
    0.4
    0.5
    0.5
    0.5
    0.5
    Return Loss (dB)
    55/50
    Operating Temperature
    -40~+85
    Directivity (dB)
    ≥ 55
    Storage Temperature
    -40~+85
    2xN PLC Splitter Specification
    Operating Wavelength(nm)
    1260~1650
    Fiber Type
    G657A1 or as customers' order
    Port Configuration
    2x2
    2x4
    2x8
    2x16
    2x32
    2x64
    2x128
    Insertion Loss (dB)
    4.0
    7.6
    11.0
    14.4
    17.5
    21.0
    24.5
    Loss Uniformity (dB)
    0.6
    1.0
    1.2
    1.5
    1.8
    2.2
    2.5
    Polarization Dependent Loss(dB)
    0.2
    0.2
    0.3
    0.3
    0.35
    0.4
    0.4
    Wavelength Dependent Loss(dB)
    0.3
    0.4
    0.5
    0.5
    0.5
    0.5
    0.5
    Temperature Dependent Loss (-40~85 ) (dB)
    0.4
    0.4
    0.5
    0.5
    0.5
    0.5
    0.5
    Return Loss (dB)
    55/50
    Operating Temperature
    -40~+85
    Directivity (dB)
    ≥ 55
    Storage Temperature
    -40~+85
    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3
    Mini Tube/ABS Box/Plug-in PLC Splitter 1x4 1x8 SC APC for Fiber Optic FTTH and 3
    Q: The location of our factory?

    A: Our factory is located in Ningbo, Zhejiang, and our new factory has also been put into production, located in the Northeast
    (Jilin Province).

    Q: An occupied area for our factory?

    A: The construction area of our factory is about 23,000 square meters, including 8000 square meters in Fenghua Plant and 15,000
    square meters in Northeast China.

    Q: Production capacity for the PLC splitter?

    A: 800,000 pcs per month.

    Q: What's your best price for your passive fiber optic product?

    A: Based on the quality of our products and the quantity of your estimated. We would quote the great best matching price all the
    time.

    Q: Do you offer a guarantee for the products?

    A: Yes, we offer a 1-2 years warranty on our formal products.
