    Unbalanced 1x5 Single Mode Fiber Distribution PLC Splitter with High Reliability

    Ask Lasest Price
    Model Number : Unbalanced PLC Splitter
    Brand Name : FIbconet
    Price : $1.50/boxes 500-4999 boxes
    • Product Details
    • Company Profile

    Unbalanced 1x5 Single Mode Fiber Distribution PLC Splitter with High Reliability

    Product Description
    Unbalanced 1x5 Single Mode Fiber Distribution PLC Splitter with High Reliability

    APPLICATIONS

    · FTTx · Cable television (CATV) · Local area networks (LAN) · Test equipment · Passive optical networks(PON)
    Unbalanced 1x5 Single Mode Fiber Distribution PLC Splitter with High Reliability

    FEATURE

    · Wide operating wavelength range: from 1260nm to 1650nm · Wide Operating Temperature: from -40ºC to 85ºC · Good channel-to-channel uniformity · High reliability and small size · Adopt high-strength stainless steel, pass the salt spray test · Adopt 100% new raw material, ROHS compliance · Low Insertion loss&Low PDL Compact Design
    Unbalanced 1x5 Single Mode Fiber Distribution PLC Splitter with High Reliability
    Description
    The transmission power of the PLC Splitter's CH1 output port can be customized, and the remaining optical power is split evenly by the CH2-CH5 four output ports.
    Specification
    1xN PLC Splitter Specification
    Operating Wavelength(nm)
    1260~1650
    Fiber Type
    G657A1 or as customers' order
    Port Configuration
    1x2
    1x4
    1x8
    1x16
    1x32
    1x64
    1x128
    Insertion Loss (dB)
    3.8/4.0
    7.1/7.3
    10.2/10.5
    13.5/13.7
    16.5/16.9
    20.5/21.0
    23.8/24.2
    Loss Uniformity (dB)
    0.4
    0.6
    0.8
    1.2
    1.5
    2.0
    2.5
    Polarization Dependent Loss(dB)
    0.2
    0.2
    0.2
    0.25
    0.3
    0.35
    0.4
    Wavelength Dependent Loss(dB)
    0.3
    0.3
    0.3
    0.5
    0.5
    0.5
    0.5
    Temperature Dependent Loss (-40~85 ) (dB)
    0.4
    0.4
    0.4
    0.5
    0.5
    0.5
    0.5
    Return Loss (dB)
    55/50
    Operating Temperature
    -40~+85
    Directivity (dB)
    ≥ 55
    Storage Temperature
    -40~+85
    2xN PLC Splitter Specification
    Operating Wavelength(nm)
    1260~1650
    Fiber Type
    G657A1 or as customers' order
    Port Configuration
    2x2
    2x4
    2x8
    2x16
    2x32
    2x64
    2x128
    Insertion Loss (dB)
    4.0
    7.6
    11.0
    14.4
    17.5
    21.0
    24.5
    Loss Uniformity (dB)
    0.6
    1.0
    1.2
    1.5
    1.8
    2.2
    2.5
    Polarization Dependent Loss(dB)
    0.2
    0.2
    0.3
    0.3
    0.35
    0.4
    0.4
    Wavelength Dependent Loss(dB)
    0.3
    0.4
    0.5
    0.5
    0.5
    0.5
    0.5
    Temperature Dependent Loss (-40~85 ) (dB)
    0.4
    0.4
    0.5
    0.5
    0.5
    0.5
    0.5
    Return Loss (dB)
    55/50
    Operating Temperature
    -40~+85
    Directivity (dB)
    ≥ 55
    Storage Temperature
    -40~+85
